UKS210LN
| Cr | 35 | kN | Basic dynamic load rating |
| C0r | 23.2 | kN | Basic static load rating |
Included products
| Bearing | UKS210LN | Bearing |
Associated products
| Adapter sleeve | H2310X | Adapter sleeve |
Nominal Dimensions
| d | 50 | mm | Bore diameter |
| D | 90 | mm | Outside diameter |
| B1 | 55 | mm | Overall bearing width |
| d1 | 45 | mm | Sleeve bore diameter |
| d2 | 70 | mm | Outside diameter lock nut |
| B,B4 | 32 | mm | Width of inner ring |
| B2 | 12 | mm | Width lock nut including lock washer |
| C | 24 | mm | Outer ring width |
| r(min.) | 1.5 | mm | Chamfer dimension |
| d4 | 62.4 | mm | Outside diameter of inner ring |
| D1 | 86.79 | mm | Diameter of snap ring groove |
| a | 3.7 | mm | Distance outer ring from side face to snap ring groove |
| b | 2.85 | mm | Width of snap ring groove |
| Mass approx. | 0.97 | kg | Mass approx. |
