QJ322
| d | 110 | mm | Bore diameter |
| D | 240 | mm | Outside diameter |
| B | 50 | mm | Width |
| r (min.) | 3 | mm | Chamfer dimension |
| Ca | 355000 | N | Basic dynamic load rating |
| C0a | 710000 | N | Basic static load rating |
| Grease | 2200 | min-1 | Grease lubrication |
| Oil (Oil-bath) | 3000 | min-1 | Oil-bath lubrication |
| da (min.) | 124 | mm | Diameter of shaft abutment |
| Da (max.) | 226 | mm | Diameter of housing abutment |
| ra (max.) | 2.5 | mm | Radius of shaft or housing fillet |
| (approx.) | 12.5 | kg |
