R1
| d | 1.397 | mm | Bore diameter |
| D | 4.762 | mm | Outside diameter |
| B | 1.984 | mm | Width |
| r (min.) | 0.1 | mm | Chamfer dimension |
| Cr | 255 | N | Basic dynamic load rating |
| C0r | 66 | N | Basic static load rating |
| Grease | 90000 | min-1 | Grease lubrication |
| Oil (Oil-bath) | 110000 | min-1 | Oil-bath lubrication |
| da (min.) | 2.2 | mm | Diameter of shaft abutment |
| Da (max.) | 3.9 | mm | Diameter of housing abutment |
| ra (max.) | 0.1 | mm | Radius of shaft or housing fillet |
| (approx.) | 0.00015 | kg |
